Condition:
New
Positioning Accuracy (mm):
0.02 mm
No. of Spindles:
Single
Working Table Size(mm):
1300Ã2500
Machine Type:
CNC Router
Travel (X Axis)(mm):
1300 mm
Travel (Y Axis)(mm):
2500 mm
Repeatability (X/Y/Z) (mm):
0.02 mm
CNC or Not:
CNC
Voltage:
380V, 3phase, 60Hz
Dimension(L*W*H):
3200*2140*1850mm
Weight (KG):
1500
Control System Brand:
Mach3, DSP
Warranty:
1 Year
Key Selling Points:
Multifunctional
Applicable Industries:
Hotels, Machinery Repair Shops, Food & Beverage Factory, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Energy & Mining, Food & Beverage Shops
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Motor, Pump
Working area:
1300*2500*200mm
Control system:
NCstudio 53B control system with wireless handle
Spindle:
6kw Italy HSD air cooling spindle
Spindle speed:
0-18000RPM
Motor and driver:
Japan YASKAWA 850w servo motor and driver
Inverter:
7.5kw E type Taiwan DELTA inverter
Reducer:
Japan SHIMPO reducer for X,Y axis
Linear rail:
Taiwan #20 HIWIN linear guide
X,Y axis transmission:
X,Y axis rack and pinion drive
Weight:
1400kg
After-sales Service Provided:
Video technical support
Local Service Location:
Peru, India, Mexico, Japan, Malaysia, Argentina, South Korea, Algeria, Sri Lanka
After Warranty Service:
Video technical support, Online support, Field maintenance and repair service
Showroom Location:
Italy, Brazil, Peru, India, Mexico, Kenya, Colombia
Marketing Type:
New Product 2020
Certificação:
CE ISO9001 SGS BV TUV ISO9000
